JAFFA Metal Cladding
JAFFA metal cladding is the ideal solution for modern ventilated facades and stylish interiors, combining visual elegance, durability, and discreet fastening for a perfect result.
I WANT A PRICE ESTIMATION
If you would like more information about this product or request a personalized price estimation, please contact us through this form.
It is a waterproof facade system for cladding ventilated facades
The recessed panel system can be used on both walls and soffits.
It has a flat surface and complements any architectural metal roofing system. With JAFFA metal cladding, we can create an attractive, lightweight, and durable exterior façade cladding.
It can also be used as an interior design element.
JAFFA cladding is fastened to the frame with self-tapping screws, which are concealed.
TECHNICAL DRAWING
TECHNICAL DETAILS
| Material |
Thickness (mm) |
Roofing Weight m2 (kg) |
Entry Width (mm) |
Overall Coverage Width (mm) |
Length (mm) |
Battens (mm) |
Profile Height (mm) |
Colors |
| Textured Galvanized Steel Sheet LPL | 0,50 | 5,40 | 416,60 | 290 |
300 ÷ 6 000 (longer upon agreement) |
400 | 10 |
RAL 3009 TXT, RAL 7016 TXT, RAL 8004 TXT, RAL 8017 TXT, RAL 9005 TXT, RAL Extra Golden Oak TXT RAL Extra Dark Oak TXT |
| Textured Aluminum Sheet AL | 0,70 | 2,57 | 416,60 | 290 |
300 ÷ 6 000 (longer upon agreement) |
400 | 10 |
RAL 7016 TXT, RAL 8017 TXT, RAL 9010 TXT, RAL Extra Corten TXT, RAL Extra Light Wood TXT RAL Extra Magahony Wood TXT |
Material
MOUNTING METHOD
JAFFA cladding is fastened to 40 × 30 mm wooden battens or to metal profiles (using a fastening method similar to drywall constructions) with wood screws (4.0 × 30 mm) / metal screws (4.0 × 20 mm). Batten spacing is every 40 cm (wall) and every 60 cm (ceiling). The cladding is installed using 6 screws per m². The surface weight of aluminum sheet (AL) is 3 kg/m². The surface weight of coated steel sheet (LP) is 6.25 kg/m².
JAFFA cladding is fastened to 40 × 30 mm wooden battens or metal profiles (using a mounting method similar to drywall constructions) with wood screws (4.0 × 30 mm) or metal screws (4.0 × 20 mm).
Batten spacing every 40 cm (wall) and every 60 cm (ceiling).
The cladding is installed using 6 screws per m².
The surface weight of aluminum sheet (AL) is 3 kg/m².
The surface weight of coated steel sheet (LP) is 6.25 kg/m².
SYSTEM OF SHEET METAL COMPONENTS
Cover Strip
Outer Corner
Inner Corner
End Trim
Joint Trim
Omega Mounting Profile
Trim
